BIK 2pcs M18 Proximity Sensor NPN NC 6-36VDC 8mm Detective Approach Sensor Inductive Proximity Switch
4.0 (72 items)
Limited Time SaleUS$30.28 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211038807 | Release Date | 2026/04/04 | List Price | US$20.18 | Model Number | 211038807 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Model number:LJ18A3-8 series External dimensions:M18x60 Installation type:Shielded Detection distance:8mm Setting distance:0-7 mm Supply voltage:6-36Vdc If communication is AC90-250V Output current:DC type:300mA max;AC Type:400mA Standard detected object:Mild steel (18x18x1mm)Sensing object:Magnetic metals (if it is not magnetic metals,the sensing distance would decrease)Response frequency:500Hz Output indication:Red LED Short-circuit protection:NO Reverse connection protection:Yes Insulation resistance:50MΩ min (between charging part and housing)Dielectric strength:1000Vac,1min(between charging part and housing)IP Rating:IP65 Operating temperature:25 to 70°C(13 to 158°F)Cable length:1.2m,PVC cable Material:Case:Brass-nickel plated;Sensing surface:ABS
- Product Name :Inductive Proximity Switch;Model:LJ18A3-8-Z/AX;Theory:Inductive Sensor;Wire Type :3 Wire Type(Brown,Blue,Black)
- Switch Appearance Type:Cylinder Type,Metal Shell;Output Type :NPN NC;
- Theory:Inductive Sensor;Detecting Distance :8mm Sensor;Diameter of Head:16mm/0.63";Thread diameter:18mm
- Size:6.8 x 3.3cm/2.7"x 1.3"(L*Max.Dia);Cable Length :1.1m/3.6Ft;External Material :,Alloy
- Net Weight :80g;Color:Blue Black ;Package Content :2 x Inductive Proximity Switch
| Color | One Color |
|---|---|
| Model | BIK |
| Brand Name | BIK |
| Unit Count | 1.0 Count |
| Item Weight | 500 Grams |
| Manufacturer | BIK |
| Material Type | PVC |
| Number of Items | 1 |
